BG Technical Characteristics
Solid lubricant and start up film
- The inserts are positioned overlapping in the sliding direction.
- The lubrication film will deteriorate over time but is replaced with lubrication provided by the inserts
- Once the bearing is fully machined, a 20 microns film of a similar composition to the solid lubricant inserts may be applied. This film eases the critical start up process (stick-slip).
| Type | Description | Micrography |
|---|---|---|
| L2 | Standard use lubricant. Temperature range up to: 250ºC. |  |
| LHT | Special lubricant for use in high temperatures between 250 and 500 ºC. |  |
| E2 | Lubricant made with low conductivity elements for sea water environments. |  |
